The ION C3100 is a fiber to fiber media converter module. It is protocol independent and supports data rates from 100Mbps to 2.5Gbps through two open SFP slots. This any-rate to same-rate converter can be used to perform reliable and cost-effective single mode to multimode fiber conversion or it can be used to provide wavelength conversion in CWDM applications. The ION C3100 is a manageable device when installed in a managed ION chassis.
- General Information
- Manufacturer
- Lantronix, Inc
- Manufacturer Website Address
- http://www.lantronix.com
- Brand Name
- Transition Networks
- Product Line
- ION
- Packaged Quantity
- 1
- Product Type
- Transceiver/Media Converter
- Warranty
- Limited Warranty
- Lifetime
- Media & Performance
- Media Type Supported
- Optical Fiber
- Fiber Mode Supported
- Multi-mode
- Single-mode
- Maximum Data Transfer Rate
- 2.50 Gbit/s
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP (mini-GBIC)
- Number of SFP Slots
- 2
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Network Technology
- 100Base-X
- 2.5GBase-X
- Power Description
- Power Source
- AC/DC
- Power Consumption
- 3 W
- Physical Characteristics
- Height
- 3.4"
- Width
- 0.9"
- Depth
- 6.5"
- Weight (Approximate)
- 1 lb
- Miscellaneous
- Application/Usage
- Data
- Compatibility
MSA Compliant
- Certifications & Standards
- NDAA
- FCC Class A
- EN55022 Class A
- EN55024,
- CE Mark
- Environmentally Friendly
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
